EIF CORES |
 |
| CORES |
DIMENSIONS(mm) |
| A |
B |
C |
D |
E |
F |
I |
| EIF14 |
14.0±0.3 |
10.7min |
3.0±0.2 |
5.0±0.2 |
2.0±0.2 |
3.5±0.15 |
1.5±0.15 |
| EIF18 |
18±0.4 |
13.6min |
4.0±0.2 |
10.0±0.25 |
2.0±0.2 |
4.0±0.2 |
2.0±0.15 |
| EIF22 |
21.8±.0.4 |
16.4min |
5.0±0.25 |
15.8±0.3 |
3.2±0.2 |
5.7±0.3 |
2.5±0.25 |
| EIF32 |
31.75±0.65 |
25.4±0.5 |
6.35±0.15 |
20.35±0.4 |
3.2±0.15 |
6.35±0.15 |
3.15±0.15 |
| EIF38 |
38.1±0.9 |
30.8±0.6 |
76±0.2 |
25.4±0.55 |
4.45±0.15 |
8.25±0.15 |
3.8±0.15 |
| EIF43 |
43.2±0.8 |
35.4±0.7 |
8.1±0.2 |
27.9±0.6 |
5.4±0.15 |
9.5±0.15 |
4.1±0.15 |
| EIF64 |
64±1.3 |
53.6±1.1 |
10.2±0.2 |
50.8±1.1 |
5.1±0.15 |
10.2±0.15 |
5.1±0.15 |
| CORES |
EFFECTIVE PARAMETERS |
WEIGHT (g) |
AL ± 25%(nH/N 2 ) |
| C 1 (mm -1 ) |
Ae(mm 2 ) |
Le(mm) |
Ve(mm 3 ) |
|
| EIF14 |
1.21 |
13.7 |
16.6 |
228 |
1.4 |
1250 |
| EIF18 |
0.54 |
37.4 |
20.2 |
757 |
4.1 |
2900 |
| EIF22 |
0.33 |
78.0 |
26.0 |
2028 |
10.2 |
5200 |
| EIF32 |
0.27 |
130.0 |
35.1 |
4560 |
24 |
6300 |
| EIF38 |
0.22 |
194.0 |
43.6 |
8440 |
44 |
8200 |
| EIF43 |
0.22 |
229.0 |
50.4 |
11500 |
60 |
8500 |
| EIF64 |
0.13 |
519.0 |
69.7 |
36200 |
185 |
14000 |
| In the table no size, may attempt the processing with provided samples manufacture according to the customer |
|
|
