| PRODUCT ATTRIBUTE |
| Matersal |
Code |
Remanence |
Coercivity
force |
Intrinsic
Coercivity
force |
Max
onergy
product |
Cune
temp |
Max
Operating
Temp |
| . |
. |
Br |
bMc |
Hc |
(BM)max |
TC |
TW |
| T |
KGs |
KA/m |
KOe |
KA/m |
KOe |
HJ/m2 |
MGOe |
°C |
°C |
| Sintered |
SmCo
(1:5) |
ZBX-18 |
0.85 |
8.5 |
620 |
7.8 |
≥1350 |
≥17 |
145-150 |
17-19 |
750 |
250 |
| ZBX-20 |
0.90-0.96 |
9.0-9.6 |
653-717 |
8.2-9.0 |
1194-1513 |
15-19 |
150-175 |
19-22 |
750 |
250 |
| ZBX-24 |
1.0 |
10.0 |
680 |
8.5 |
≥1195 |
≥15 |
175-190 |
22-24 |
750 |
250 |
| ZBX-26 |
1.02 |
10.2 |
750 |
9.5 |
≥1195 |
≥15 |
195-215 |
24-26 |
750 |
250 |
SmCo
(2:17) |
ZBXG-24 |
0.95-1.02 |
9.5-10.2 |
637-732 |
8.0-9.2 |
1433-1990 |
18-25 |
175-190 |
22-24 |
800 |
300 |
| ZBXG-26 |
1.02-1.05 |
10.2-10.5 |
748-796 |
9.4-10.0 |
1433-1990 |
18-25 |
195-215 |
24-26 |
800 |
300 |
| ZBXG-28 |
1.05-1.08 |
10.5-10.8 |
756-796 |
9.5-10.0 |
1433-831 |
18-23 |
205-220 |
26-28 |
800 |
300 |
| ZBXG-30 |
1.08 |
10.8 |
780 |
9.8 |
≥955 |
≥15 |
220-240 |
28-30 |
800 |
300 |
| Bonded |
SmCo
(1:5) |
ZB-6 |
0.4 |
4.0 |
280 |
3.5 |
800 |
10 |
30-50 |
4-6 |
/ |
120 |
| ZBb-10 |
0.5 |
0.5 |
320 |
4.0 |
800 |
10 |
50-65 |
6-8 |
/ |
120 |
SmCo
(2:17) |
ZBG-10 |
0.6 |
0.6 |
360 |
4.5 |
800 |
10 |
65-80 |
8-10 |
/ |
120 |
| ZBG-12 |
0.7 |
0.7 |
400 |
5.0 |
800 |
10 |
80-95 |
10-12 |
/ |
120 |
|
 |
 |
 |
|
| |
|
